JASU H-500 High Speed High Precision 3 Axis Horizontal CNC Machining Center

FOB Reference Price:Get Latest Price
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Horizontal
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
JASU
Model Number:
H-500
Voltage:
220V/380V
Power(W):
12 kw
Dimension(L*W*H):
2600x2000x2200 mm
Weight:
4000kg
Certification:
ISO CE
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Machine type:
Horizontal Milling
Spindle taper:
BT40
Spindle speed:
10000rpm
XYZ axis travel:
600/600/400 mm
XYZ axis rapids:
48/48/48 m/min
SupplyAbility
SupplyAbility:
15 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden case
Port
Guangzhou / Shenzhen
Lead Time :
30 days

JASU H-500 High Speed High Precision 3 Axis Horizontal CNC Machining Center



*Machine frame is made by advanced iron casting material, internal stress eliminated by aging treatment. With box shape structure, the frame has excellent performance for machining and accuracy requirements.


*Machine adopts high speed linear guide for 3 axes, for high speed and high precision movement;


*High accuracy and high quality ball screw is adopted for 3 axes, preloaded to prevent termal deformation, to ensure the positioning accuracy;


*High speed spindle motor makes it suit for both high efficiency and high precision machining requirement;

*Heat exchanger is installed in electricity cabinet to guarantee the stable of system. Coiler is equipped out side, it is heat, oil and water-resistant;



*Automatic Centralized Lubrication System can provide timely and accuracy lubrication according to the lathe situation to make sure the machine can work continuously;



Specification

H-500

Worktable



Worktable size

500 x 500 mm

T slot size (No.-W-G)

M12 x 80 mm

NC rotary table (Opt.)

500

Table size

500 x 500 mm

Index accuracy

4 sec

Repeatability

1 sec

Max. loading capacity

400 kg

Travel



X/Y/Z axis travel

600/600/400 mm

Spindle center to table

100-700 mm

Spindle end face to table center

140-540 mm

Spindle



Spindle taper

BT40

Max. spindle speed

10000 rpm

Drive method

Belt drive

Spindle motor power

5.5/7.5 KW

Feeding



XYZ axis cutting feedrate

1 -10000 mm/min

XYZ axis rapid traverse

48 m/min

XYZ servo motor power (Fanuc)

1.2/1.2/1.8 KW

Ballscrew spec.

Ø32-P16

Positioning accuracy (JIS)

±0.003/300 mm

Repeatability (JIS)

±0.003 mm

ATC



ATC type

Arm type

Tool capacity

24 + 1 pcs

Max. tool dia. x length

80 x 200 mm

Max. tool weight

8 kg

Tool change time (T-T)

< 2.8 sec

General



Coolant motor

0.49 KW

Air required

8 KG

Power capacity

15 KVA

Overall dimension

2.6 x 2.0 x 2.2 m

Net weight

4000 kg





Standard configuration

Optional configuration

1.Fanuc/Mitsubishi/Siemens CNC controller
2.RS-232 standard interface
3.RS-232 transmission cable
4.Heat exchanger of electrical cabinet
5.Enclosed cover
6.Auto centralized lub. system
7.Coolant system
8.Spindle rigid tapping
9.Working light
10.Tri-color signal light
11.Pendant handle
12.Coolant gun
13.Safety door
14.Toolkit for setup
15.Leveling blocks and bolts
16.Operation maintenance manual





1.Arm type ATC-T24/T32/T40

2.Chain plate type chip conveyor and chip cart

3.Coolant through spindle

4.Spindle 12000rpm

5.Spindle oil chiller

6.NC rotary table

7.Voltage stabilizer

8.Oil mist filter

9.Enclosed top cover
11.Tool setting system
12.Workpiece measuring system
13.Linear scale
