JASU L-5075 CNC Turning Center with VDI turret for Precision milling drilling tapping function

FOB Reference Price:Get Latest Price
US $36,000-60,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Horizontal
CNC or Not:
CNC
Automatic Grade:
Automatic
Max. Swing Diameter:
450mm
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
JASU
Model Number:
L-5075
Voltage:
380V
Power(W):
11/15kw
Dimension(L*W*H):
2500x1675x1800mm
Weight:
4500kg
Certification:
CE ISO
After-sales Service Provided:
Engineers available to service machinery overseas
Control System:
FANUC/Mitsubishi/GSK system
Parts:
Germany/Japan
Tailstock travel:
650 mm
Turret type:
VDI40
Driven tool speed:
4000rpm
Supply Ability
Supply Ability:
50 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden box
Port
Guangzhou
Lead Time :
Shipped in 60 days after payment

JASU L-5075 CNC Turning Center with VDI turret for precision milling drilling tapping function



Advantages of L-5075 CNC Turning Center:

1.Adopted high quality components, such as FAG bearings, Rexroth linear guide, Hiwin ballscrews and Schneider electric parts.

2.CNC control, motors and servo system are same brand, such as Fanuc, Mitsubishi or Siemens control package,  thus controbility is more stable.

3.Monoblock slant bed casting body obtains better riditity, one piece headstock casting increases output torque of spindle.

4.Servo motors are directly coupled with ballscrews, which guarantees the transmission precision and torque. Ballscrews are pretensioned to eliminate transmission backlash and precomensates error from heat growth.

5.Precision linear guide are adopted for X/Z axis, to achieve high speed while keeps high precision at same time. Travel speed of X/Z axis is 24/30 m/min.

6.Taiwan made hydraulic 3-jaw chuck has large clamping force and precision.Elastic collet chuck is optional.

7.Adopted VDI 40 live tool servo turret matched with spindle C axis and brake system is specially suitable for complex parts processing.

8.Fully enclosed design makes it safe to operator.

9.CE certificate.



Brand

JASUModelL-5075
Max. Machining Dia.500mmMax. Machining Length750mm
Max. X/Z Axis Travel 250/800mmTurret TypeVDI turret
ControllerFANUC/MitsubishiTools Capability12



L-5075 jasu cnc latheL-5075



 JASU Hot Sell CNC Machine Models



V-600 Travel 600/450/500mm

V-850D Travel 800/500/500mm

V-1060D Travel 1000/600/600mm

V-1270D Travel 1200/700/700mm

V-1470D Travel 1400/700/700mm

V-2090D Travel 2000/900/800mm

V-650S Travel 650/400/500mm Pallet Changer

V-600Z Travel 600/450/350 mm

V-600S Travel 600/400/350mm Pallet Changer



H-500 Travel 600/400/600mm

H-630 Travel 720/600/500mm

H-630S Travel 720/600/500mm Pallet Changer

H-800 Travel 950/700/600mm

H-800S Travel 950/700/600mm Pallet Changer

H-1400T Travel 1400/900/700mm

H-1900T Travel 1900/1400/9000mm

H-2300T Travel 2300/1900/1000mm

M-2016 Travel 2000/1600/800mm

M-2516 Travel 2500/1600/800mm

M-3016 Travel 3000/1600/800mm





ITEM L-5075
Processing CapacityMax. swing diam. over bed 500mm
Max. swing diam. over slide 250mm
Max. machining diam.420mm
Max. machining length750mm
Bed Tilt Angle45°
SpindleTaper of spindle boreA2-6
Chuck10’’
Spindle bore 61/49
Spindle speed4000rpm
FeedingX/Z axis travel250/800mm
X/Z axis rapid moving speed24/30m/min
Lead screw 3208/4010
Min. resolution0.001mm
MotorSpindle motor11/15Kw
X/Z-axis servo motor2.5/2.5Kw
Coolant motor0.49Kw
Hydraulic motor power2HP
TailstockTailstock travel650
Tailstock quill travel100
Tailstock quill dia.Φ72
Tailstock quill taperMT4
Turret Turret typeVDI 40 turret
Turret capacity12 position (12 live tools)
Tool shank size25x25mm
Boring blade diameterΦ32mm
GeneralPower Capacity15KVA
Overall dimensions2500x1675x1800
N.W.4500kg





JASU L-5075 CNC Turning Center with VDI turret   features:



1.Machine bed:  JASU L-5075 CNC Turning Center   machine body is made of inoculated casting HT-300, internal stress eliminated by special method. With the exquisite design, the bed has excellent performance for machining and accuracy requirements.


2.Transmission Shaft:  JASU L-5075 CNC Turning Center adopt P4 grade linear guide for X/Z axis for faster speed and better precision ;


3.Lead Screw: High accuracy and high quality ball screw is adopted for  L-5075 CNC turning center to make sure the positional accuracy;


4.Spindle Motor: High quality motor make sure that the lathe perform well at high or low speed and light or heavy cutting(11/15Kw);



5.Electrical Cabinet: Heat exchanger is installed in electricity cabinet to guarantee the stable of system. Coiler is equipped out side, it is heat, oil and water-resistant;



6.Lubrication System:  Automatic Centralized Lubrication System of  L-5075 CNC turning center  can provide timely and accuracy lubrication according to the lathe situation to make sure the machine can work continuously;



7.Advanced FANUC/Mitsubishi Controller.



Standard Accessories Optional Accessories
1.Fanuc /Mitsubishi/GSK Controller;
2.Heat Exchanger for Electrical Cabinet;
3.RS-232 user interface;
4.RS-232 communication cable;
5.Hydraulic 3-jaw chuck;
6.VDI Power turret;
7.Spindle C axis & positioning brake;
8.Working lamp;
9.Closed type anti-splash device;
10.Automatic centralized lubrication system;
11.Isolated transformers;
12.Tools box;
13.Operation manual;
14.Maintenance manual;
15.Leveling screws and pads.

1.Taiwan SYNTEC controller;
2.Chip conveyor and chip container;

3. Oil mist filter;
4. Barfeeder;

5. Automatic parts catcher.

6.Steady rest
