Quick Details

  • Condition: New
  • Type: Vertical
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: JASU
  • Model Number: V-1060B
  • Voltage: 220V/380V
  • Power(W): 7.5/11kw
  • Dimension(L*W*H): 3.2*3.1*2.9m
  • Weight: 6T
  • Certification: CE
  • Warranty: 1 year warranty
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Worktable Size: 1300x600 mm
  • X/Y/Z Travel: 1300/600/600 mm
  • CNC controller: Mitsubishi/FANUC/Siemens/GSK

Packaging & Delivery

Packaging Details Wooden Case,Standard,Export Package.
Delivery Time About 20 working days after receiving your deposit

JASU V-1060B Boxway Heavy Duty Vertical CNC Machine Center



* V-1060D machine center  body is optimized design by computer CAD/CAM, with the structure of wide body and column.Casting by the quality Meehanite resin sand process. Times effect of aging treatment times,



* The adoption of C3 grade precise ball screws and the use of special bearing on the ball screw with pre-pull treatment as well as laser detective compensation have ensured the rigidity and precision.



* The adoption of balance weight block with motion-based device has prevented the spindle form vibration when weight-balanced block moves up and down, avoiding influencing the processing accuracy.



* The main base parts of   V-1060B Vertical CNC Machine Center  is made from high-grade ,high quality gray casting iron with aging treatment, the guide rails with high-frequency quenching treatment and delicate grinding ,covered with low frictional coefficient TURCITE-B and dealt with delicate scraping ,having effectively improved motional quality of machine and necessary touching rigidity for cutting.





CNC Machine V-B Series Specification:

Model

V-850B

V-1060B

V-1370B

V-1580B

Worktable



Worktable size

1050x500

1300x600

1400x710

1700x800

T slot size

5x18x90

5x18x100

5x22x120

5x22x135

Max. Loading capacity

600KG

800kg

1000kg

1500kg

Travel



XYZ axis travle

800/500/500

1000/600/600

1300/700/600

1500/800/680

Spindle nose to worktable110-610120-720140-790160-840
Spindle center to column560630770880
Feeding

X/Y/Z axis rapid travel

18/18/12m/min

18/18/12m/min

18/18/12m/min

18/18/12m/min

Cutting feedrate

10000 mm/min

10000 mm/min

10000 mm/min

10000 mm/min

Ballscrew specification

Φ40-P10

Φ40-P10

Φ50-P10

Φ50-P10

Spindle



Spindle taper

BT40

BT40

BT50

BT50

Spindle speed

8000rpm

8000rpm

6000rpm

6000rpm

Spindle drive

Belt

Belt

Belt

Belt

Spindle speed (Option )

10000rpm

10000rpm

8000rpm

8000rpm

ATC



Arm type ATC

T24

T24

T24

T24

Max. tool weight

7 kg

7 kg

7 kg

7 kg

Max. tool dia. x length

80 x 200 mm

80 x 200 mm

120 x 300 mm

120 x 300 mm

Tool change time (T-T)

<2.8 sec

<2.8 sec

<4.8 sec

<4.8 sec

Servo motor



Spindle motor

7.5/11KW

7.5/11KW

11/15KW

15/18.5KW

X/Y/Z axis motor Fanuc

1.8/1.8/1.8KW

2.5/2.5/2.5KW

3.0/3.0/3.0KW

3.0/3.0/3.0KW

Coolant pump

0.49 KW

0.49 KW

0.49 KW

0.49 KW

General datas



Air required

8 KG8 KG8 KG8 KG

Power capacity

15 KVA20 KVA30 KVA30 KVA

Dimensions

2.7x2.4x2.5m

3.2x2.5x2.8m

3.6x2.7x2.9m

4.3x3.3x3.0m

Net weight

5T

6T

10.5T

13.5T





Standard Configuration

Optional Configuration

  1. FANUC controller 0i MF;
  2. Standard CF card interface;
  3. RS-232 interface;
  4. RS-232 transmission cable;
  5. Spindle rigid tapping;
  6. Arm type tool magazine 24 tools;
  7. Fully enclosed splash cover;
  8. Working lamp;
  9. Heat exchanger for electrical cabinet;
  10. Automatic centralized lubrication system;
  11. Toolbox for setup;
  12. Operation manual;
  13. Maintenance manual;
  14. Leveling screws and pads;
  15. Weight balance system.
  1. GSK/Siemens/Mitsushi controller;
  2. Chip conveyor and chip bucket;
  3. Spindle 10000rpm/12000rpm
  4. Automatic voltage stabilizer;
  5. Oil mist filter.
  6. CNC rotary table (4th, 5th axis);
  7. Spindle Gearbox .





V-1060B China Boxway 4 Axis Vertical CNC Machine Cente:



1.Machine bed:  V-1060B Vertcial CNC Milling Machine is made HT-300 inoculated iron casting material, internal stress eliminated by artificial and natural aging treatment. With the exquisite design, the bed has the excellent performance for machining and accuracy requirements.


2.Transmission Shaft: JASU V-1060B Vertcial CNC Machine Center  adopt hardened and ground boxway guide, made by the advanced resin sand casting material, load ability improved greatly;


3.Lead Screw: High accuracy and high quality pretensioned ballscrews are adopted for CNC Milling Machine to ensures high positioning accuracy;


4.Spindle Motor: High quality servo motor with 7.5/11kw power for spindle makes it perform well at high or low speed and light or heavy cutting;



5.Electrical Cabinet: Heat exchanger is installed in electricity cabinet to guarantee the stable of system. Coiler is equipped out side, it is heat, oil and water-resistant;



6.Lubrication System: Automatic Centralized Lubrication System of   JASU V-1060B Boxway Type Vertcial CNC Machine Centercan provide timely and accuracy lubrication according to the lathe situation to make sure the machine can work continuously;



7.Advanced FANUC/Mitsubishi Controller.



Machine center

vertical cnc machine center

vertical cnc milling machine







Gauangzhou Jasu Precision Machinery Co.Ltd is a sabusidiary of JASU International Machinery Group locates in Guangzhou China, which is top 3 supplier of CNC machine tools in South China. JASU owns R&D center and factories in Guangzhou and Suzhou. JASU has been dedicated to manufacturing CNC lathe, machining center, Gantry CNC milling machine and machine tool accessories for 20 years.


Absorbing the design and manufacture of Taiwan and Germany, JASU create a series of highly distinctive, automatic and cost-effective CNC Machine Tools, machine accessory and one step Injection (Stretch) Blow Molding Machine. JASU has got high reputation and trust among customers by means of modern management method, perfect quality, novel design and reasonable price.


Our company faith is “better and faster, it is JASU”.  We are engaged in providing machines with high quality and best service to create benefit for enterprise and create value for customer.
