JASU V-1580D Heavy Duty CNC Vertical Machining Center Fanuc

FOB Reference Price:Get Latest Price
US $10,000-100,000 / Sets | 1 Set/Sets (Min. Order)
Key Company Capacity
Production Capacity >
  • Employees: 101 - 200 People
  • Factory Size: 30,000-50,000 square meters
  • No. of Production Lines: Above 10
Research & Design >
  • No.of R&D Engineer: 21 - 30 People
Trade Capacity >
  • Export Mode: Have Own Export License
  • Export Percentage: 41% - 50%
  • No. of Employees inTrade Department: 3-5 People
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Vertical
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
JASU
Model Number:
V-1580D
Voltage:
220V/380V
Power(W):
15/18.5 kw
Dimension(L*W*H):
4.3x3.1x3.0 m
Weight:
15000 kg
Certification:
CE ISO9001
controller:
Fanuc/Siemens/Mitsubishi
type:
vertical
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 year
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden case
Port
Guangzhou
Lead Time :
60 days

JASU V-1580D Heavy Duty CNC Vertical Machining Center



ASU V-D series traveling beam type vertical CNC machining center is middle size range of vertical CNC milling machine center with high speed and high rigidity. It is a new generation of JASU VMC products owning national patent.



The models has full processing function of milling, boring, drilling, tapping and reaming etc. It can be equipped with full enclosed-loop linear scales, high pressure coolant through spindle, 4 axes simultaneous motion etc. It is exactly suitable to the application in various industries, like machinery, automobile, mould, aerospace, motor and valves etc.

Specification of V-D Series Vertical Machining Center

SpecificationV-1580DV-2090D
Worktable
Table size (L*W)1700 x 800 mm2200 x 1000 mm
T slot size (width * gap)18 x 142 mm18 x 165 mm
T slot number 6 pcs 6 pcs
Max. load capacity 2000 kg3000 kg
Travel
Max. XYZ axis travel 1500/800/700 mm2000/900/800 mm
Spindle nose to worktable 200-900 mm250-1050 mm
Spindle center to column surface950 mm1200 mm
Spindle
Spindle taper BT50/SK50/CT50BT50/SK50/CT50
Max. spindle speed 6000rpm8000rpm
Spindle drive Belt drive Belt drive
Feeding
XYZ axis cutting feedrate1-10000 mm/min1-10000 mm/min
XYZ axis rapid traverse 20/20/20 m/min20/20/20 m/min
XYZ axis ballscrew size XYZ:∅50-P10
XYZ:∅50-P10
Positioning accuracy (JIS)±0.003/300 mm±0.003/300 mm
Repeatability (JIS)±0.003 mm ±0.003 mm
A.T.C.(Option)
Tool magazine typeArm type Arm type
Tool capacity 24 pcs24 pcs
Max. tool diameter X length 112 x 300 mm112 x 300 mm
Max. tool weight15 kg15 kg
Toolholder typeBT50/SK50/CT50BT50/SK50/CT50
Tool change time (T-T)4.8 sec.4.8 sec.
Servo motor power
Spindle motor 15/18.5 kw 15/18.5 kw
XYZ axis servo motor (Mitsubishi)3.0/3.0/3.0 kw3.0/3.0/3.0 kw
XYZ axis servo motor (Fanuc)3.0/3.0/3.0 kw3.0/3.0/3.0 kw
Coolant motor 0.49 kw0.49 kw
General items
Air required 8 kg8 kg
Power capacity30 KVA30 KVA
Dimensions3.4 x 3.3 x 3.0 m4.5 x 3.3 x 3.0 m
Net weight 15000 kg18000 kg



Standard and optional configuration

Standard configuration

Optional configuration

1.Fanuc/Mitsubishi/Siemens CNC controller
2.RS-232 standard interface
3.RS-232 transmission cable
4.Heat exchanger of electrical cabinet
5.Enclosed cover
6.Auto centralized lub. system
7.Coolant system
8.Spindle rigid tapping
9.Working light
10.Tri-color signal light
11.Pendant handle
12.Coolant gun
13.Safety door
14.Toolkit for setup
15.Leveling blocks and bolts
16.Operation maintenance manual

1.Arm type ATC-T24

2.Chain plate type chip conveyor and chip cart
3.Coolant through spindle

4.Direct spindle BT50-8000rpm
5.Spindle oil chiller

6.NC rotary table - 4th axis (320,400)
7.Voltage stabilizer
8.Oil mist filter
9.Enclosed top cover
10.Tool setting system
11.Workpiece measuring system
12.Linear scale

















Gauangzhou Jasu Precision Machinery Co.Ltd is a sabusidiary of JASU International Machinery Group locates in Guangzhou China, which is top 3 supplier of CNC machine tools in South China. JASU owns R&D center and factories in Guangzhou and Suzhou. JASU has been dedicated to manufacturing CNC lathe, machining center, Gantry CNC milling machine and machine tool accessories for 20 years.


Absorbing the design and manufacture of Taiwan and Germany, JASU create a series of highly distinctive, automatic and cost-effective CNC Machine Tools, machine accessory and one step Injection (Stretch) Blow Molding Machine. JASU has got high reputation and trust among customers by means of modern management method, perfect quality, novel design and reasonable price.


Our company faith is “better and faster, it is JASU”.  We are engaged in providing machines with high quality and best service to create benefit for enterprise and create value for customer.



Overseas Agent Wanted


In order to further develop the international market, we are sincerely invite you to be our agent, on the basis of equality and mutual benefit.



As our agent, quite favorable price, professional technical instruction and excellent after-sale service will be offered.
